Researchers Say Google Street View Could Aid in Assessing Damage After Natural Disasters

Photographs from Google Street View before and after a major natural disaster could help researchers and civil engineers to assess the damage to buildings and improve resistance against future events, according to new research from the University of Southampton, United Kingdom.

The research, published in the Institution of Civil Engineers’ (ICE) journal Civil Engineering, studied images taken before and after the 2011 Japan earthquake to assess the impacts on buildings from the devastating Tōhoku tsunami, which hit the east coast of Honshu, Japan.

Following normal field team investigations to assess damage and provide information to aid future design guidelines, Google Street View cars were sent around major cities and coastal areas, photographing streets over a six-month period starting four months after the tsunami. Images were compiled with those taken before the event to produce an accessible digital archive to allow comparison of the ‘before’ and ‘after’ situations. The resulting images were displayed online (Google Street View, 2011).

Southampton researchers compared images from two Japanese cities, Ishinomaki, on a coastal plain, and Ofunato, on a ‘ria’ coastline with steep coastal valleys. ‘After’ images were used to identify the material and form of structures that remained standing, which were logged by location and graded on a damage scale. Buildings that could be used for sheltering and siting of structures to serve as vertical evacuation centres were also assessed.

“We found that much of what is observable in the field is also visible in the online archive. The Google Street View cars created a new resource for remote assessment of structural performance, quantitatively by type and location and qualitatively for beneficial design features, such as sheltering by trees and other buildings,” said study co-author Dr Alan Bloodworth, lecturer in Engineering and the Environment at the University of Southampton. “Although such online images cannot completely replace field surveys, they have the potential to exploit an untapped resource of researchers around the world, who can then collaborate with local engineers to learn lessons and improve tsunami resistance of vulnerable coastal communities.”

“The Tōhoku tsunami highlighted the vulnerability of cities to such natural disasters and the need to improve survivability. Advances in technology have made remote data collection possible as an alternative to field investigations. The availability of readily comparable images can provide individual building performance assessment, but with much less use of resource and with the ability to make connections between different occurrences of particular successful structural forms,” said co-author Jessica Miles, a graduate from the University of Southampton.

Source: University of Southampton
